ROTHER ERDER SLEWING RING MODEL
Xinda manufactures standard and customized slewing bearings in various designs, with outside diameters from 0,2 to 8 m to meet the demands of particular applications.
Mainly Products
1. Four-point contact ball slewing ring
2. crossed roller slewing ring
3. Double-row ball slewing ring
4. Three-row roller slewing ring
5. Light Flanged Slewing Ring
6. Trailer Turntable
We also can produce below most poluar model for Rother Erder Slewing Ring:
|
Model |
OD |
ID |
Heigtht |
Teeth No. |
Weight |
|
250.14.0300.013 |
401 |
233 |
40 |
Ungeared |
9.6 |
|
250.14.0400.013 |
501 |
333 |
40 |
Ungeared |
13.1 |
|
250.15.0300.013 |
401 |
233 |
40 |
Ungeared |
9.6 |
|
250.15.0400.013 |
501 |
333 |
40 |
Ungeared |
13.1 |
|
250.15.0375.013 |
400 |
234 |
40 |
Ungeared |
9.6 |
|
250.15.0475.013 |
500 |
334 |
40 |
Ungeared |
13.1 |
|
230.20.0400.013 |
518 |
304 |
56 |
Ungeared |
23.4 |
|
230.20.0500.013 |
648 |
434 |
56 |
Ungeared |
31 |
|
230.20.0600.013 |
748 |
534 |
56 |
Ungeared |
36.4 |
|
230.20.0700.013 |
848 |
634 |
56 |
Ungeared |
42.8 |
|
230.20.0800.013 |
948 |
734 |
56 |
Ungeared |
47.8 |
|
230.20.0900.013 |
1048 |
834 |
56 |
Ungeared |
53.1 |
|
230.20.1000.013 |
1198 |
984 |
56 |
Ungeared |
61.9 |
We can provide sepcial service according to customer’s requirment.
This method ------ slewing bearing is after special treatment, and has the function of anticorrosion-------it is widely used in many fields that need to be anticorrosive, such as container crane, steel mill-----which adapt to the damp & bad circumtance, so the life of the slewing rings will can be relatively extended.
If you have your specific parameter and requirements for our slewing ring bearings, customization is available.
| Standard series KD210 | |||||
| Model | OD | ID | Heigtht | Teeth No. | Weight |
| 250.14.0300.013 Typ 13/400 |
401 | 233 | 40 | Ungeared | 9.6 |
| 250.14.0400.013 Typ 13/500 |
501 | 333 | 40 | Ungeared | 13.1 |
| 250.15.0300.013 Typ 13/400 |
401 | 233 | 40 | Ungeared | 9.6 |
| 250.15.0400.013 Typ 13/500 |
501 | 333 | 40 | Ungeared | 13.1 |
| 250.15.0375.013 Typ 13/400 |
400 | 234 | 40 | Ungeared | 9.6 |
| 250.15.0475.013 Typ 13/500 |
500 | 334 | 40 | Ungeared | 13.1 |
| 230.20.0400.013 Typ 21/520.0 |
518 | 304 | 56 | Ungeared | 23.4 |
| 230.20.0500.013 Typ 21/650.0 |
648 | 434 | 56 | Ungeared | 31 |
| 230.20.0600.013 Typ 21/750.0 |
748 | 534 | 56 | Ungeared | 36.4 |
| 230.20.0700.013 Typ 21/850.0 |
848 | 634 | 56 | Ungeared | 42.8 |
| 230.20.0800.013 Typ 21/950.0 |
948 | 734 | 56 | Ungeared | 47.8 |
| 230.20.0900.013 Typ 21/1050.0 |
1048 | 834 | 56 | Ungeared | 53.1 |
| 230.20.1000.013 Typ 21/1200.0 |
1198 | 984 | 56 | Ungeared | 61.9 |
