MTO-050 Slewing bearings

MTO-050 Specifications

Type of raceway structure:Single raceway ball bearing

Max Outer diameter:4.331 inch (110.01mm)

Min Inner diameter:1.968 inch (49.99mm)

Overall height:0.787 inch(19.99mm)

External bolt circle diameter:3.818 inch(96.98mm)

Hole in outer ring:8

Internal bolt circle diameter:2.480 inch(62.99mm)

Hole in inner ring:8

Tooth Number:toothless


Product type advantages

Characteristic of structure,performance and application for MTO-050 Slewing bearings

That is single-row four points contact ball Slewing Bearing ,which composed of 2 seat-rings.It features compact in design,and light in weight.The balls contact with the circular race at four points,via which the axial force,radial force and resultant moment may be born simultaneously.

Order advantage

1.The advantages of products' quality and competitive price

2.Reply within 24 hours

3.Could learn customers' requirement/need very well

4.Professional sales team to contact you easily, fluently and conveniently

5.Terminal manufacturer to remove redundant procedures between us

6.Have a good control for quality, from raw material, assembling, inspection to packing


 It usually used for slewing converter,welding arms and positioning,light,medium Engineering, metallurgy, mining, petroleum, chemical industry, light industry, aviation,  military and instrument and other industries.


Other similar models

Standard series MTE-470, MTE-470T , MTO-540, MTO-540T, MTE-540, MTE-540T, MTO-590, MTO-590T, MTE-590, MTE-590T
