062.20.0844.575.01.1403 Slewing Bearing

062.20.0844.575.01.1403 Slewing Bearing Slewing Bearing(XD series slewing ring bearing)

Type of raceway structure:Single Row Slewing Bearing

Max Outer diameter:914.5mm

Min Inner diameter:737.6mm

Overall height:56mm

External bolt circle diameter:890mm

Internal bolt circle diameter:805mm

Tooth Number:94

Tooth NO.:94

Weight:69kgs


Details

Product type advantages

062.20.0844.575.01.1403 slewing bearing mainly includes the external ring & internal ring, the grease fittings, the sealing belt, the spacers, the load plug and the taper pin, the characteristics: the internal ring and the external ring are both L-shaped; The flank surface of ring is provided with a grease cup, steel balls is assembled between the external ring and internal ring on integration. each ball is separated by spacer, the steel balls and the spacers are installed through the load plug, and the taper pin to protect the ball running. Light type profile slewing bearing has the same structure with general slewing bearing , it features in weight , swivel flexible .

Order advantage

Serious raw material inspection;

Strict control over the entire manufacturing process;

Sampling of all the products after final inspection before shipment;

Quality trace after delivery.



Application

062.20.0844.575.01.1403 slewing bearing widely used in food machinery , filling machinery , environment protection machine and so on .

single row ball
2007830155332201
single row ball

Other similar models

060.20.0844.575.01.1403,062.20.0844.500.01.1503,060.20.0844.500.01.1503,061.20.0844.500.01.1503,061.20.0844.575.01.1403,VLA200844-N,VLI200844-N,VLU200844,VSI200844-N,VSU200844,XSAI140844-N,XSU140844,RKS.062.20.0844,RKS.060.20.0844,RKS,161.14.0844,RKS,162.14.0844,RKS,160.14.0844
