Best Quality VSA200414-N Slewing Bearings

VSA200414-N Specifications

Type of raceway structure Single raceway
Max Outer diameter 503.3mm
Min Inner diameter 342mm
Overall height 56mm
External bolt circle diameter 455mm
Internal bolt circle diameter 368mm
Module 5mm
Tooth Number 99
Theoretical Weight 31kgs


Details

Product type advantages

Single Row Four Point Contact Ball Slewing Bearing

Characteristic of structure,performance and application

The single-row four points contact ball Slewing Bearing is composed of 2 seat-rings.It features compact in design,and light in weight.The balls contact with the circular race at four points,via which the axial force,radial force and resultant moment may be born simultaneously.

Order advantage

1.Stable quality, competitive price

2.Slewing rings dia.100-6000mm

3.Focus on clients' needs

4.Customized order,OEM/ODM services

5.Passed ISO9001 Certificate

6.Special designs available

7.high quality, reasonable price,complete after-sales service

Application

Single Row Four Point Contact Ball Slewing Bearing used for slewing converter,welding arms and positioning,light,medium duty cranes,excavators and other engineering machines.

Other similar models

Please contact us for more model:

Rollix Balls Without Gear

03-0181-07, 03-0217-00, 03-0260-00, 03-0342-05, 03-0360-00, 03-0402-00, 03-0525-01

03-0600-02, 03-0785-00, 03-0980-02, 03-0181-07
