VLU200944 INA Slewing Bearing

VLU200944 INA Slewing Bearing

Type of raceway structure:Single Row Slewing Bearing

Max Outer diameter:1048mm

Min Inner diameter:834mm

Overall height:56mm

External bolt circle diameter:1020mm

Internal bolt circle diameter:862mm

Dimensions: Bore (Inner) Diameter: 834 mm

Tolerance: +0,7/0

Outer Diameter: 1048 mm

Tolerance: 0/-0,7

Width (Thickness): 56 mm


Details

Product type advantages

VLU200944 INA Light slewing bearing mainly includes the external ring & internal ring, the grease fittings, the sealing belt, the spacers, the load plug and the taper pin, the characteristics: the internal ring and the external ring are both L-shaped; The flank surface of ring is provided with a grease cup, steel balls is assembled between the external ring and internal ring on integration. each ball is separated by spacer, the steel balls and the spacers are installed through the load plug, and the taper pin to protect the ball running. Light type profile slewing bearing has the same structure with general slewing bearing , it features in weight , swivel flexible .

Order advantage

1.Stronger loading capacity

2.Large size/diameter

3.ISO 9001:2008 certificate

4.OEM available

Application

VLU200944 INA Light slewing bearing widely used in food machinery , filling machinery , environment protection machine and so on .

Other similar models

VLU200414,VLU200544,VLU200644,VLU200744
